• Gas Washing Bottle

Gas Washing Bottle

GASW-250

  • Lab and Research

Vendor: OMSONS

Suited For: Lab and Research

Country of Origin: India

30-Day Limited Warranty
This product is covered against manufacturing defects in materials and workmanship for 30 days from the date of purchase.

This warranty does not cover: breakage caused by thermal shock (rapid heating or cooling); physical or mechanical damage, including drops, impacts, chips, and cracks from handling; damage from use outside the glassware's rated temperature, pressure, or chemical compatibility; damage from improper cleaning; normal wear such as scratching, staining, or discolouration; or unauthorised repair or modification.

To claim, contact SmartLabs within 30 days of purchase with proof of purchase and a description of the defect.
Low stock! Only 2 left
R 500.00
R 500.00
Tax included. Shipping calculated at checkout.
  • Fast Nationwide Delivery
  • 100% Quality Guaranteed
  • Reliable & Secure Payments

Have a question about this product?

Send us a message and we'll get back to you.

Drechsel (Dreschel) glass gas washing bottle with interchangeable joint head and round base. Can be used to remove impurities from gasses. Inlet / Outlet Glass tubes measure 5mm inside diameter. Total height of the bottle is approx. 11 inches. Made of borosilicate glass.

Design:

  • Complete Set: Includes a reservoir bottle and a detachable head with an inlet and outlet tube.
  • Inlet/Outlet Tubes: Standard glass tubes measuring approximately 8 mm internal diameter.
  • Bubbling Action: The inlet tube extends to the bottom of the bottle to ensure gas bubbles through the liquid medium for maximum absorption or scrubbing efficiency.
Primary Applications
  • Gas Purification: Removing impurities (like moisture or specific vapors) from a gas stream by bubbling it through a scrubbing liquid.
  • Humidifying: Saturating a dry gas with water vapor.
  • Gas Washing: Removing acidic or alkaline vapors from gas emissions.
How to use a gas washing bottle
  1. Place the gas washing bottle in a secure place.
  2. Fill the bottle with the choice liquid.
  3. Grease the joints.
  4. Connect the tubing to the 2 external glass tubes from the bottle, with the gas entry tube to the long tube, and the gas exit to the shorter tube.
  5. Begin pumping gas through the bottle.

Specifications

  • Material: Clear 3.3 Borosilicate Glass
  • Joint Size: Select from drop down
  • Tube Connector: Glass thread Connector
  • Brand: OMSONS
  • Product of India

Specifications

Height: Approx. 11 Inches
Inlet/Outlet Tube Diameter: 5mm ID
Material: Borosilicate Glass
