• Adapter Still Head with Thermometer, Recovery Vertical Adapter

Adapter Still Head with Thermometer, Recovery Vertical Adapter

CNW-5042-14/19

  • Borosilicate

Vendor: SmartLabs

Suited For:

Country of Origin:

Low stock! Only 4 left
R 275.00
R 275.00
Tax included. Shipping calculated at checkout.
  • Fast Nationwide Delivery
  • 100% Quality Guaranteed
  • Reliable & Secure Payments

Have a question about this product?

Send us a message and we'll get back to you.

A Vertical Recovery Adapter with Thermometer Port (also known as a Vertical Still Head) is a specialized 3-way connector. It allows you to mount a condenser vertically while simultaneously monitoring the temperature of the ascending vapour.

Key Features

  • Design: A vertical glass body with three distinct openings:
    • Top Joint (Socket): A smaller standard ground joint (usually 14/23) designed to hold a thermometer adapter.
    • Side-Arm Joint (Cone): An angled or vertical outlet that connects to the condenser.
    • Bottom Joint (Cone): Connects directly to the boiling flask or fractionating column
  • Material: Manufactured from high-quality Borosilicate Glass 3.3, providing high thermal shock and chemical resistance.
  • Joints: Equipped with precision ground-glass joints (typically Standard Taper) to create leak-free seals, which are critical for maintaining pressure or vacuum conditions.
  • Drip Tip: Many models include an integrated drip tip to ensure precise liquid handling and prevent "wicking" back into the ground joint.
Core Applications
  • Solvent Recovery: Ideal for large-scale solvent reclaim in teaching, research, and industrial laboratories.
  • Distillation Assemblies: Acts as a bridge between the boiling flask and the rest of the apparatus in setups where space or equipment requires a vertical alignment.
  • Reflux Systems: Facilitates the return of condensed vapours to the boiling flask during reflux experiments.
  • Essential Oil Extraction: Used in specific extraction kits to guide vapours from biomass flasks into cooling zones.
Common Joint Sizes & Pricing
Typical joint sizes for these adapters include:
  • 14/23
  • 19/26
  • 24/29
  • 29/32

Specifications:

  • Material: 3.3 Borosilicate glass
  • Neck: Ground glass joint (socket)
  • Joint Sizes: 19/26, 24/29, 29/32 (Select an option)
  • Brand: NONE
  • Product of China
