• Soxhlet extraction apparatus with coil condenser for continuous solid-liquid extraction

Soxhlet Extraction Apparatus with Coil Condenser

CH-SX-500

  • Lab and Research

Vendor: OMSONS

Suited For: Lab and Research

Country of Origin: India

30-Day Limited Warranty
This product is covered against manufacturing defects in materials and workmanship for 30 days from the date of purchase.

This warranty does not cover: breakage caused by thermal shock (rapid heating or cooling); physical or mechanical damage, including drops, impacts, chips, and cracks from handling; damage from use outside the glassware's rated temperature, pressure, or chemical compatibility; damage from improper cleaning; normal wear such as scratching, staining, or discolouration; or unauthorised repair or modification.

To claim, contact SmartLabs within 30 days of purchase with proof of purchase and a description of the defect.
Out of stock
R 889.00
R 889.00
Tax included. Shipping calculated at checkout.
  • Fast Nationwide Delivery
  • 100% Quality Guaranteed
  • Reliable & Secure Payments

Have a question about this product?

Send us a message and we'll get back to you.

A Soxhlet Extraction Apparatus with a Coil Condenser (Graham or Allihn type) is the standard setup for the continuous extraction of lipids or bioactive compounds from solid materials using a volatile solvent.


Core Components
  • Boiling Flask: A flat or round-bottom flask (typically 250mL to 500mL) where the solvent is heated.
  • Soxhlet Extractor Body: The middle section containing the thimble (where your solid sample sits) and the siphon tube that automatically drains the solvent back into the flask.
  • Coil Condenser: Mounted on top to cool solvent vapors. The internal glass coil provides a larger surface area for more efficient cooling compared to a basic Liebig condenser.
  • Joints: Usually standard 24/29 or 24/40 ground glass joints for a vacuum-tight seal.

How the Extraction Works
  1. Vaporization: Solvent in the bottom flask is heated; vapors rise through the extractor's bypass side-arm.
  2. Condensation: Vapors hit the coil condenser, turn back into liquid, and drip onto the solid sample in the thimble.
  3. Soaking: The chamber fills with warm solvent, dissolving the desired compounds from the solid material.
  4. Siphoning: Once the liquid reaches the top of the siphon tube, it automatically drains back into the boiling flask, carrying the extract with it.
  5. Cycling: This process repeats automatically, concentrating the extract in the boiling flask while fresh solvent continues to cycle.
Specifications & Material
  • Glass Type: High-quality Borosilicate 3.3 for high thermal resistance and chemical durability.
  • Thimbles: Uses disposable cellulose or glass fiber thimbles (e.g., 33x80mm or 33x94mm for a 250mL extractor).
  • Efficiency: The coil condenser is particularly effective for low-boiling-point solvents like hexane, petroleum ether, or ethanol.



Specifications

Boiling Flask Capacity: 250mL to 500mL
Joint Size: 24/29 or 24/40
Material: Borosilicate 3.3 Glass
Thimble Size: 33mm x 80mm or 33mm x 94mm (for 250mL Extractor)
